Bend Version Magnetic Float Level Switch – BVFS

Description

Bend version float switches are used for applications wherein there is a mounting constraint from the top. These bend version level switches have rugged construction and can be used for both indoor & outdoor applicatons.

GENERAL SPECIFICATIONS:

• Enclosure: Cast Al, Weather-proof to IP65 Ex-proof to Gr. IIA & IIB DIN Polyamide connector.
• Conduit Connector: Brass, ¾” ET/ ½” NPT
• Guided Stem MOC: SS316 SS304
• Float MOC x Size : SS316 x Ø22, Ø28, Ø30, Ø40,Ø52, Ø89, PU Foam X Ø22, Ø25, Ø35
• Stem OD : Ø8, Ø12.7 in SS316/SS304
• Operating Temperature: SS316-Ø52, Ø40 up to 150⁰, Ø22, Ø28, Ø30 up to 100⁰C. PU Foam- Ø22, Ø25, Ø35 up to 60⁰C.
• Operating pressure max. : SS316-Ø52,Ø40 up to 20 Kg/cm2, Ø22, Ø28, Ø30 up to 8Kg/cm2. PU Foam- Ø22, Ø25, Ø35 –Atmospheric
• Min. specific gravity: 0.7 Kg/cm2
• No. of Floats: Single/ Multiple (Max. 4) (More available on request)
• Process Connections: Flanged / Triclover Flange
• Preset Levels: 1 to 4 (Factory Set) (More available on request)
• Switch type: Glass encapsulated hermetically sealed Reed contacts.
• Switching capacity : 15VA (NO) / 100VA (NO) or 3VA (1C/O) / 50VA (1C/O)
• Differental : FIXED (10± 2 mm)
• Accuracy / Repeatability : ± 2mm / ± 1mm
• Load : Resistve / Inductve
• Insulaton : 100 Mega-Ohms at 500V DC
• Special features : Intrinsically safe to EX ib Gr IIA-IIB
